This test method covers the determination of the delami- nation strength (tensile node-to-node bond strength) of honey- comb core materials. Following the possible choices to be ordered.
| Test Standard | ASTM C363 |
| Maximum Load | 4,5 kN |
| Temperature Range | da -80 °C a 149 °C |
| Mounting |
1/2”-13 threaded couplings |
| Fixture Dimensions | 50 mm x 100 mm x 152 mm |
| Fixture Material |
High strength steel with a protective finish |
| Mass | 9.00 kg |
Additional Information:
- Standard Test Method for Node Tensile Strength of Honeycomb Core Materials
- This test method covers the determination of the tensile-node bond strength of honeycomb core materials.
- The values stated in either SI units or inch-pound units are to be regarded separately as standard. The values stated in each system may not be exact equivalents; therefore, each system shall be used independently of the other. Combining values from the two systems may result in non-conformance with the standard.
- This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety and health practices and determine the applicability of regulatory limitations prior to use.
